Whoopsies
-
Common Emitter Explorer v1
PDF GuidebookThis board is significantly different than the current, v2 board which replaced it. So you may find this old guidebook PDF handy. -
Whoops Parts List
Whoops BOM Parts ListNote that the urls to specific parts, when provided in the linked spreadsheet, are just examples for demonstration's sake. Many of these parts can be found from a wide range of manufacturers and suppliers. Please purchase from your preferred vendor.
About The Whoopsies
Less than perfect, but still entirely useful.
FREE prototypes, B stock, and functional defects. At worst the products listed here will be slightly impacted by a design defect, but still entirely useful. At best they'll just be left over stock of an older product which has been replaced by a newer version.
Help me keep these subpar-but-still-totally-useful boards from a life collecting dust on my shelves.
Check back often and add a bunch to your order if you see anything that interests you. No purchase (of other items) necessary. You'll just pay the shipping.
